    Superior Strength Alloy Steel Sheet 1.7225 4140 Plate Thickness 12mm -350mm

    Ask Lasest Price
    Brand Name : CF STEEL
    Model Number : 40CrNiMoA, AISI4340,39CrNiMO,40NiCRMo22,SNCM439
    Certification : ISO, Mill Certificate
    Price : USD800-900/MT
    Payment Terms : L/C, T/T
    Supply Ability : 1000t/Month
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    Superior Strength Alloy Steel Sheet 1.7225 4140 Plate Thickness 12mm -350mm

    Superior Strength Special Alloy Steel DIN 1.7225 4140 Scm440 42CrMo4 Q + T Heat Treatment


    ► Chemical Composition(%):


    CSiMnCrPSMo
    0.38-0.450.17-0.370.50-0.800.90-1.20≤0.035≤0.0350.15-0.25

    Similar grades: GB 42CrMo / DIN 1.7225 / AISI SAE4140 / JIS SCM440


    Available size(mm):


    Flat Bar Size(mm)Round bar Size(mm)
    ThicknessWidthLengthDiameterLength
    10-200155-22002000-600020-2003000-6000

    ► Availabe shape:


    • Steel Plate
    • Flat Bar
    • Round Bar
    • Steel Block
    • Steel Sheet
    • Steel Rod

    Feature:


    1,Good strength, hardenability and toughness.


    2,High creep strength and long lasting strength under the high temperature.


    ► Surface treatment:


    Round bar: Black / Grinding / Polished / Peeled / Turned
    Steel plate: Black / Milling / Machined


    Recommend heat treatment:


    QuenchingTempering
    Heating temperature/℃Cooling wayHardness (HRC)Tempering
    temperature/ºC
    Cooling wayHardness
    (HRC)
    850-880Oil Cooling50-52450-650Air cooling≥48

    Applications:


    Used in the manufacture of high strength, large cross-section forgings such as supercharger transmission gear,rear axle,hummar shank etc.


    High strength, hardenability, good toughness, low deformation in quenching, high creep strength and endurance.Used in the manufacture requirements higher than 35 crmo steel strength and conditioning section more large forgings, such as locomotive traction with the big gear, supercharger drive gear, rear axle, the load of connecting rod and a spring clip, can also be used to under 2000 m deep well of oil drill pipe joint and the fishing tool and so on.

    Superior Strength Alloy Steel Sheet 1.7225 4140 Plate Thickness 12mm -350mm
    Superior Strength Alloy Steel Sheet 1.7225 4140 Plate Thickness 12mm -350mm

    Changfeng Tool & Die Steel main product:


    STANDARD/GRADE of steelFlat Bar Size(mm)Round bar Size(mm)Technics
    DINAISMJISGB(China)ThicknessWidthLengthDiameterLength
    1.121SAE1050S50C50#10-450155-22002000-12000Forged, Hot Rolled
    1.2311P20PDS-33Cr2Mo10-460155-22002000-1000020-2002000-6000
    1.2738P20+Ni-3Cr2NiMnMo21-300155-22002000-800020-2002000-6000
    1.2379D2SKD10SKD1010-200155-8102000-600014-803000-6000
    1.2080D3SKD13Cr2Mo10-200155-8102000-600020-2003000-6000
    1.2083420-4Cr1310-500155-12002000-600012-3003000-6000
    1.2344H13SKD614Cr5MoSiV110-500155-16002000-600016-4003000-6000
    1.2510O1SKS39CrWMn10-200155-8102000-600020-2003000-6000
    1.7225SAE4140SCM44042CrMo10-280155-22002000-600016-4503000-6000


    About Us
    Guangzhou Changfeng Steel Co., Ltd.
    is a professional special steel company, which specializing in this line in China since 2005. Our main products are Plastic Mould Steel, Hot Work Mould Steel, Cold Work Mould Steel, Alloy Structural Steel, Tool Steel, Stainless Steel, Carbon Steel and Forged Block.

    To ensure provide high quality products to customers, we have close cooperation with many Chinese first class special steel enterprises, including Baosteel Group, Dongbei Special Steel, Changcheng Special Steel, Hongsheng Heavy Industry, Xingcheng Special Steel and Daye Special Steel.
